| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGF12038_24J | 24 | 14.0~26.2 | 0.18 | 2300 | 104.44 | 2.96 | 0.23 | 5.79 | 38.0 | AGF12038_48J | 48 | 28.0~56.0 | 0.10 | 2300 | 104.44 | 2.96 | 0.23 | 5.79 | 38.0 | AGF12038_12L | 12 | 7.0~13.2 | 0.40 | 2600 | 118.14 | 3.35 | 0.29 | 7.43 | 41.0 | AGF12038_24L | 24 | 14.0~26.2 | 0.20 | 2600 | 118.14 | 3.35 | 0.29 | 7.43 | 41.0 | AGF12038_48L | 48 | 28.0~56.0 | 0.14 | 2600 | 118.14 | 3.35 | 0.29 | 7.43 | 41.0 | AGF12038_12M | 12 | 7.0~13.2 | 0.50 | 2900 | 126.90 | 3.59 | 0.32 | 8.07 | 44.0 | AGF12038_24M | 24 | 14.0~26.2 | 0.35 | 2900 | 126.90 | 3.59 | 0.32 | 8.07 | 44.0 | AGF12038_48M | 48 | 28.0~56.0 | 0.20 | 2900 | 126.90 | 3.59 | 0.32 | 8.07 | 44.0 | AGF12038_12H | 12 | 7.0~13.2 | 0.80 | 3200 | 139.98 | 3.96 | 0.39 | 9.86 | 48.0 | AGF12038_24H | 24 | 14.0~26.2 | 0.45 | 3200 | 139.98 | 3.96 | 0.39 | 9.86 | 48.0 | AGF12038_48H | 48 | 28.0~56.0 | 0.23 | 3200 | 139.98 | 3.96 | 0.39 | 9.86 | 48.0 | AGF12038_12U | 12 | 7.0~13.2 | 1.42 | 4200 | 183.75 | 5.20 | 0.67 | 17.00 | 54.0 | AGF12038_24U | 24 | 14.0~26.2 | 0.60 | 4200 | 183.75 | 5.20 | 0.67 | 17.00 | 54.0 | AGF12038_48U | 48 | 28.0~56.0 | 0.43 | 4200 | 183.75 | 5.20 | 0.67 | 17.00 | 54.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
