| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | BGN13391B48U | 48 | 28.0~56.0 | 1.3 | 4500 | 247.5 | 7.0 | 1.63 | 41.5 | 70.0 | BGN13391B48H | 48 | 28.0~56.0 | 0.8 | 4000 | 212.2 | 7.0 | 1.45 | 36.8 | 65.0 | | BGN13391B24H | 24 | 14.0~26.4 | 1.6 | 4000 | 212.2 | 6.0 | 1.45 | 36.8 | 65.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|  | - CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request.
|
|
