| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | BGN17569B12U | 12 | 7.0~13.2 | 2.8 | 3100 | 312.04 | 8.84 | 1.47 | 37.24 | 64.0 | BGN17569B24U | 24 | 14.0~26.4 | 1.5 | 3100 | 312.04 | 8.84 | 1.47 | 37.24 | 64.0 | | BGN17569B48U | 48 | 28.0~56.0 | 0.71 | 3100 | 312.04 | 8.84 | 1.47 | 37.24 | 64.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|  | - CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request.
|
|
