| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | BGE04020_05L | 5 | 4.5~5.5 | 0.16 | 3500 | 1.60 | 0.05 | 0.13 | 3.20 | 27.0 | BGE04020_12L | 12 | 7.0~13.2 | 0.08 | 3500 | 1.60 | 0.05 | 0.13 | 3.20 | 27.0 | BGE04020_05M | 5 | 4.5~5.5 | 0.20 | 4500 | 2.10 | 0.06 | 0.23 | 5.90 | 33.0 | BGE04020_12M | 12 | 7.0~13.2 | 0.10 | 4500 | 2.10 | 0.06 | 0.23 | 5.90 | 33.0 | BGE04020_05H | 5 | 4.5~5.5 | 0.25 | 5500 | 2.50 | 0.07 | 0.38 | 9.70 | 37.0 | BGE04020_12H | 12 | 7.0~13.2 | 0.15 | 5500 | 2.50 | 0.07 | 0.38 | 9.70 | 37.0 | BGE04020_12U | 12 | 7.0~13.2 | 0.10 | 6500 | 3.00 | 0.08 | 0.56 | 14.10 | 45.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|  |
** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
