| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | BGE07530_12J | 12 | 7.0~13.2 | 0.19 | 2600 | 10.90 | 0.31 | 0.31 | 7.80 | 32.1 | BGE07530_24J | 24 | 14.0~26.2 | 0.10 | 2600 | 10.90 | 0.31 | 0.31 | 7.80 | 32.1 | BGE07530_12L | 12 | 7.0~13.2 | 0.23 | 3000 | 12.70 | 0.36 | 0.36 | 9.10 | 41.4 | BGE07530_24L | 24 | 14.0~26.2 | 0.16 | 3000 | 12.70 | 0.36 | 0.36 | 9.10 | 41.4 | BGE07530_12M | 12 | 7.0~13.2 | 0.38 | 3600 | 17.00 | 0.48 | 0.48 | 12.20 | 47.5 | BGE07530_24M | 24 | 14.0~26.2 | 0.15 | 3600 | 17.00 | 0.48 | 0.48 | 12.20 | 47.5 | BGE07530_12H | 12 | 7.0~13.2 | 0.43 | 4000 | 21.40 | 0.61 | 0.62 | 15.70 | 51.3 | BGE07530_24H | 24 | 14.0~26.2 | 0.23 | 4000 | 21.40 | 0.61 | 0.62 | 15.70 | 51.3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|  |
** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
