| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | BGE09733_12L | 12 | 7.0~13.2 | 0.21 | 2200 | 16.30 | 0.46 | 0.24 | 6.20 | 43.0 | BGE09733_12M | 12 | 7.0~13.2 | 0.19 | 2700 | 20.10 | 0.57 | 0.41 | 10.30 | 45.0 | BGE09733_24H | 24 | 14.0~26.2 | 0.25 | 3600 | 28.80 | 0.82 | 0.87 | 22.00 | 52.0 | BGE09733_12H | 12 | 7.0~13.2 | 0.60 | 3600 | 28.80 | 0.82 | 0.87 | 22.00 | 52.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|  |
** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
