| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | BGE14038_12L | 12 | 7.0~13.2 | #N/A | 1400 | 23.15 | 0.66 | 0.34 | 8.57 | 41.0 | BGE14038_12L | 12 | 7.0~13.2 | #N/A | 2200 | 33.36 | 0.94 | 0.74 | 18.84 | 53.0 | BGE14038_24L | 24 | 14.0~26.2 | #N/A | 1400 | 23.15 | 0.66 | 0.34 | 8.57 | 41.0 | BGE14038_24L | 24 | 14.0~26.2 | #N/A | 2200 | 33.36 | 0.94 | 0.74 | 18.84 | 53.0 | BGE14038_12M | 12 | 7.0~13.2 | #N/A | 2500 | 37.37 | 1.06 | 0.98 | 24.97 | 56.0 | BGE14038_24M | 24 | 14.0~26.2 | #N/A | 2500 | 37.37 | 1.06 | 0.98 | 24.97 | 56.0 | BGE14038_12H | 12 | 7.0~13.2 | #N/A | 2800 | 49.47 | 1.40 | 1.46 | 37.10 | 57.5 | BGE14038_24H | 24 | 14.0~26.2 | #N/A | 2800 | 49.47 | 1.40 | 1.46 | 37.10 | 57.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|  |
** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
