| 額定電壓 | 操作電壓 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | | Model No | VAC | OP Range(V) | Watt | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | | IGC08038_1H-EC | 115 | 90/125 | 10 | 5000 | 65.65 | 1.86 | 0.51 | 13.07
| 52.0 | | IGC08038_2H-EC | 230
| 190/240 | 10 | 5000 | 65.65 | 1.86 | 0.51 | 13.07 | 52.0 | | IGC08038_2H-ECA | 115/230 | 90/240 | 10 | 5000 | 65.65 | 1.86 | 0.51 | 13.07 | 52.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|  | ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
